FEATURES
- Suplied with any type of fiber optic
- Totally dielectric
- Thermoplastic sheath is low smoke emission, halogen-free and resistant to the spread of fire and flame, specially recommended for indoor use
TECHNICAL SPECIFICATIONS
Seath marking
| TELNET-RI | Year | Fibers No. | Fiber type | Type of cover | Lenght |
|---|---|---|---|---|---|
| TELNET-RI | 2015 | 32 F.O. | XX | TKT | 0001 |
TKT weigth and dimensions
| Fo/cable | No. active tubes | No. pasive tubes | fo/tube | Nominal diameterl (mm) | Nominal weight (kg/km) |
|---|---|---|---|---|---|
| 16 | 4 | 2 | 4 | 12.9 | 185 |
| 32 | 4 | 2 | 8 | 12.9 | 185 |
| 64 | 8 | 0 | 8 | 14.7 | 225 |
| 128 | 8 | 8 | 16 | 18.7 | 330 |
